 DIN 125
B (ISO 7090) Plain Washer Without Chamfer
|
Used for |
d |
D |
S |
|
M
1 |
1.1 |
3 |
0.3 |
|
M
1.2 |
1.3 |
3.5 |
0.3 |
|
M
1.4 |
1.5 |
4 |
0.3 |
|
M
1.6 |
1.7 |
4 |
0.3 |
|
M
1.7 |
1.8 |
4.5 |
0.3 |
|
M 2 |
2.2 |
5 |
0.3 |
|
M 2.5 |
2.7 |
6 |
0.5 |
|
M 2.6 |
2.8 |
7 |
0.5 |
|
M
3 |
3.2 |
7 |
0.5 |
|
M
3.5 |
3.7 |
8 |
0.5 |
|
M
4 |
4.3 |
9 |
0.8 |
|
M
5 |
5.3 |
10 |
1 |
|
M
6 |
6.4 |
12 |
1.6 |
|
M 7 |
7.4 |
14 |
1.6 |
|
M
8 |
8.4 |
16 |
1.6 |
|
M 10 |
10.5 |
20 |
2 |
|
M 12 |
13 |
24 |
2.5 |
|
M 14 |
15 |
28 |
2.5 |
|
M
16 |
17 |
30 |
3 |
|
M
18 |
19 |
34 |
3 |
|
M
20 |
21 |
37 |
3 |
|
M
22 |
23 |
39 |
3 |
|
M
24 |
25 |
44 |
4 |
|
M
27 |
28 |
50 |
4 |
|
M
30 |
31 |
56 |
4 |
|
M
33 |
34 |
60 |
5 |
|
M
36 |
37 |
66 |
5 |
|
M
39 |
40 |
72 |
6 |
|
M
42 |
43 |
78 |
7 |
|
M
45 |
46 |
85 |
7 |
|
M
48 |
50 |
92 |
8 |
|
M
52 |
54 |
98 |
8 |
|
M
56 |
58 |
105 |
9 |
|
M
60 |
62 |
110 |
9 |
|
M
64 |
66 |
115 |
9 |
|
M
68 |
70 |
120 |
10 |
|
M
72 |
74 |
125 |
10 |
|
M
76 |
78 |
135 |
10 |
|
M
80 |
82 |
140 |
12 |
|
M
85 |
87 |
145 |
12 |
|
M
90 |
93 |
160 |
12 |
|
M
100 |
104 |
175 |
14 |
>>
